Name: Main Combi Eco Boiler HE
Price: 1399.00 GBP
Availability: InStock

Main Combi Eco Boiler HE

FROM: £1,399.00 inc. Parts & Labour

Output

25KW
30KW

Main Combi Eco Boiler HE is the perfect boiler choice for your home because they are equipped with high technology that you can rely on and also are manufactured with lightweight materials to ensure quick and easy installation.

Main Combi Eco Boiler HE is competitively priced for those on a budget and need a quick new boiler installation to bring the worm back into the house and comes with 5 years of guarantee from Gas Line to give you good peace of mind.

Main Combi Eco Boiler HE is environmentally friendly

New Main Combi Eco boiler is part of a Main Eco range of SEDBUK Band A which was designed based on the idea of the people to protect the environment but also to meet all their requirements for home.

We are proud to have the opportunity to offer boiler installation services for Main Combi boilers being their first product of SEDBUK Band A range helping all house holders to make part on the environment protection.

You can choose the best output (Main Combi 25 Eco or Main Combi 30 Eco) to suit your need also helping you to save money on energy.

Sedbuk2_0

Features and Benefits

2 Year Parts and Labour Warranty available from Gas Line
High Efficiency SEDBUK Band A
Low NOx Emissions - class 5
No compartment ventilation required
Integral frost protection
User friendly controls
Made in the UK to ISO 9000 quality standard

Technical Information

Main Combi Eco Boiler HE	UNIT	25kW	30kW
Controls
User adjustable CH (combi only) & DHW temperature		Yes	Yes
Covered controls		Yes	Yes
Fault status display		Yes	Yes
Integral 24 hr electro-mechanical timer		Standard	Standard
Integral 7 day electronic timer		Optional	Optional
Wireless programmable room thermostat		Optional	Optional
Gas
Natural gas		Yes	Yes
Inlet supply pressure (natural gas)	mbar	20	20
Gas rate	m³bar	2.76	3.17
Heat input (maximum)	kW	28.92	32.54
Heat output – condensing (maximum)	kW	26.95	30.2
Heat output – condensing (minimum)	kW	8.37	9.42
Heat output – non-condensing (maximum)	kW	25.94	28.63
Heat output – non-condensing (minimum)	kW	7.61	8.56
Domestic hot water flow rate (maximum) @ 35°c rise	litres/min	10.2	12.3
Domestic hot water flow rate (minimum)	litres/min	2	2
SEDBUK (2005)		91.0%	A-90.1%
SEDBUK (2009)		89.0%	88.7%
NO_x	Class	5	5
Electrical
Electrical supply	Volts/Hz	230/50	230/50
Power consumption	Watts	150	150
External fuse rating	Amps	3	3
Ingress protection rating (as supplied)		IPX4D	IPX4D
Pump overrun		Yes	Yes
24hr pump exercise		Yes	Yes
Integral frost thermostat (boiler protection only)		Yes	Yes
Mechanical & hydraulic
DHW system pressure (maximum)	bar	8	8
DHW operating pressure (minimum)	bar	0.15	0.15
Safety pressure discharge	bar	3	3
Integral automatic bypass		Yes	Yes
CH system capacity (maximum)	litres	125	155
Gas supply pipe size	mm	22	22
Flow & return pipe size (CH)	mm	22	22
Flow & return pipe size (DHW)	mm	15	15
Filling loop		Standard	Standard
Compartment ventilation required		No	No
noPre-plumbing jig		Standard	Standard
Flue systems
Standard concentric flue diameter	mm	60/100	60/100
Maximum equivalent length (60/100)	m	10	10
